I2C Communication Issues with Nvidia Jetson Orin Nano Dev Board

Issue Overview

Users are experiencing difficulties establishing I2C communication between the Nvidia Jetson Orin Nano Developer Kit and external sensors. The specific problems include:

• Inability to configure pins for I2C communication correctly
• Challenges in transmitting and receiving data
• Unsuccessful attempts to connect using various configurations, including pins (3,5) and (27,28)
• Failed connectivity attempts using both Arduino Uno board and an IIC dual UART module
• The issue persists despite successful communication between two Arduino Uno boards

The problem occurs during the setup and configuration phase of the project, which utilizes Python for programming. This issue significantly impacts the ability to interface with sensors, hindering project progress and functionality.

Possible Causes

1. Incorrect Pin Configuration: The Jetson Orin Nano may have specific pin requirements for I2C communication that differ from other boards.

2. Software Driver Issues: The necessary I2C drivers may not be properly installed or configured on the Jetson Orin Nano.

3. Hardware Compatibility: The IIC dual UART module or sensors may not be fully compatible with the Jetson Orin Nano’s I2C implementation.

4. Power Supply Problems: Insufficient or unstable power supply to the sensors or IIC module could prevent proper communication.

5. Conflicting GPIO Usage: Other system processes or configurations might be interfering with the I2C pins.

6. Improper Python Library Usage: The Python code may not be correctly utilizing the I2C libraries specific to the Jetson platform.

7. Misconfigured I2C Bus Speed: The I2C clock speed might not be set correctly for the connected devices.

8. Faulty Connections: Physical connection issues, such as loose wires or incorrect wiring, could prevent proper communication.

Troubleshooting Steps, Solutions & Fixes

1. Verify Pin Configuration:

   • Consult the Jetson Orin Nano Developer Kit documentation to confirm the correct pins for I2C communication.
   • Use the sudo i2cdetect -l command to list available I2C buses and their corresponding pins.

2. Check I2C Driver Status:

   • Run sudo modprobe i2c-dev to ensure the I2C driver is loaded.
   • Verify I2C tools are installed: sudo apt-get install i2c-tools

3. Scan for I2C Devices:

   • Use sudo i2cdetect -y <bus_number> to scan for connected I2C devices on the specified bus.

4. Enable I2C in Device Tree:

   • Edit /boot/extlinux/extlinux.conf and add i2c_tegra.load_module=yes to the APPEND line.
   • Reboot the system after making changes.

5. Check Power Supply:

   • Ensure stable 3.3V or 5V (as required) is supplied to the sensors and IIC module.
   • Use a multimeter to verify voltage levels at connection points.

6. Isolate GPIO Conflicts:

   • Review /sys/kernel/debug/gpio to check for any conflicting GPIO usage.
   • Temporarily disable other GPIO-using applications or services.

7. Verify Python I2C Library:

   • Install the appropriate I2C library for Jetson: sudo pip3 install Jetson.GPIO

   • Use the following Python code snippet to test I2C communication:

     import Jetson.GPIO as GPIO
     import smbus
     import time

     # Set up I2C bus
     bus = smbus.SMBus(1)  # Use 1 for /dev/i2c-1

     # Example: Read from I2C device with address 0x48
     address = 0x48

     try:
         while True:
             data = bus.read_byte(address)
             print(f"Read data: {data}")
             time.sleep(1)
     except KeyboardInterrupt:
         print("Stopped by user")
     finally:
         GPIO.cleanup()


8. Adjust I2C Bus Speed:

   • Modify the I2C bus speed if necessary:

     sudo sh -c 'echo 10000 > /sys/bus/i2c/devices/i2c-1/bus_clk_rate'


   • Replace ‘10000’ with the desired clock rate in Hz.

9. Check Physical Connections:

   • Verify all connections are secure and correctly wired.
   • Use a logic analyzer or oscilloscope to probe the SDA and SCL lines for proper signaling.

10. Test with Known Working Device:

    • Connect a simple, known working I2C device (e.g., a basic sensor) to isolate potential compatibility issues.

11. Update Jetson Software:

    • Ensure the Jetson is running the latest software version:

      sudo apt update
      sudo apt upgrade


12. Consult Nvidia Developer Forums:

    • If the issue persists, create a detailed post on the Nvidia Developer Forums, including:
      • Exact hardware setup
      • Software versions
      • Troubleshooting steps attempted
      • Any error messages or logs

By systematically working through these troubleshooting steps, users should be able to identify and resolve the I2C communication issues with their Nvidia Jetson Orin Nano Developer Kit. If problems persist, further investigation with Nvidia support may be necessary.
