Setting Up a DHCP Server on Nvidia Jetson Orin Nano

Issue Overview

Users are experiencing difficulties setting up a DHCP server on the Nvidia Jetson Orin Nano, specifically for the ethernet port (eth1) that connects to cameras. The primary symptoms include the inability of the DHCP server to assign IP addresses to connected devices, leading to connectivity issues. This problem occurs during the configuration of the network settings and is influenced by the hardware setup, where one ethernet port (eth0) has internet access while eth1 is intended for camera connections. The issue appears to be consistent among users attempting similar configurations, significantly impacting their ability to utilize connected cameras effectively.

Possible Causes

• Hardware Incompatibilities or Defects: Issues may arise if the ethernet ports or connected cameras are malfunctioning or incompatible with the Jetson Orin Nano.
• Software Bugs or Conflicts: The JetPack version or underlying Ubuntu system may have bugs affecting network services.
• Configuration Errors: Incorrect settings in network configuration files could prevent the DHCP server from functioning correctly.
• Driver Issues: Outdated or incorrect drivers for the ethernet interfaces may lead to connectivity problems.
• Environmental Factors: Power supply issues or overheating could affect performance and functionality.
• User Errors or Misconfigurations: Incorrectly following setup instructions can lead to failures in establishing a DHCP server.

Troubleshooting Steps, Solutions & Fixes

1. Check Ethernet Connections:

   • Ensure that eth1 is properly connected to the cameras and that its link is active. Use ifconfig to verify the status of both ethernet ports.

2. Verify DHCP Server Configuration:

   • Confirm that the DHCP server is enabled for eth1. Use:

     sudo systemctl enable jetson-networking


   • Reboot the device to apply configurations.

3. Edit Configuration Files:

   • Modify /opt/nvidia/jetson-configs/jetson-camif.conf to ensure eth1 is correctly named as the camera interface:

     CAMERA_INTERFACES=("eth1")


4. Check IP Address Assignment:

   • Use the following command to check if IP addresses are being assigned correctly:

     dhcp-lease-list --lease /run/jetson/networking/jetson-dhcp-server.leases


5. Test Static IP Configuration:

   • If DHCP fails, consider assigning static IP addresses directly to each camera if they support it, as this may simplify connectivity.

6. Update Drivers and Software:

   • Ensure that you are using the latest version of JetPack and relevant drivers for your hardware setup.

7. Review System Logs:

   • Check system logs for any errors related to networking services using:

     journalctl -u jetson-networking


8. Consult Documentation:

   • Refer to Nvidia’s official networking documentation for Jetson devices here.

9. Consider Environmental Factors:

   • Ensure that your power supply is adequate and that the device is not overheating during operation.

10. Community Support:

    • Engage with forums and community discussions for additional insights and solutions from other users who have successfully configured their systems.

By following these steps, users should be able to diagnose and potentially resolve issues related to setting up a DHCP server on their Nvidia Jetson Orin Nano devices.
