Jetson Orin Nano: Issues with USB Device Detection and GPIO Configuration

Issue Overview

Users are experiencing difficulties with USB device detection and GPIO configuration on the Jetson Orin Nano Developer Kit. Specifically, users have reported that the Huawei 4G module (ME909S-821) is not recognized when connected via USB, and GPIO pins intended for USB VBUS detection are marked as "used," preventing their functionality. This situation arises when trying to connect multiple devices, leading to confusion over the proper configuration and usage of the GPIO pins.

Relevant Hardware and Software Specifications

• Device: Jetson Orin Nano Developer Kit (8GB)
• USB Device: Huawei 4G module (ME909S-821)
• Operating System: Ubuntu 20.04
• Connection Method: USB

Symptoms

• The command lsusb does not list the Huawei 4G module when connected.
• The dmesg output shows no relevant logs indicating recognition of the USB device.
• Other USB devices (e.g., mouse, keyboard) are recognized without issue.
• Attempts to use the device result in no data being transmitted or received.

Possible Causes

1. Driver Issues: The necessary drivers for the Huawei 4G module may not be installed or loaded correctly, preventing detection.
2. USB Cable or Port Issues: Faulty or incompatible USB cables or ports could lead to communication failures.
3. Power Supply Problems: Insufficient power supply to the USB device could prevent it from functioning properly.
4. Incompatibility with Jetson Orin Nano: The specific model of the Huawei module may have compatibility issues with the Jetson Orin Nano hardware or software.

Troubleshooting Steps, Solutions & Fixes

Step-by-Step Instructions

1. Check USB Connections:

   • Ensure that the Huawei 4G module is securely connected and test it with different USB ports on the Jetson device.

2. Check dmesg Output:

   • After connecting the device, run:

     dmesg | tail -n 20


   • Look for any messages related to USB device detection that may provide clues.

3. Verify Driver Installation:

   • Check if necessary drivers for your USB device are installed:

     lsmod | grep usb


   • If drivers are missing, consider installing them based on your device’s requirements.

4. Test Other USB Devices:

   • Connect other known working USB devices (like a mouse or keyboard) to ensure that the USB ports are functioning correctly.

5. Use Different Cables and Ports:

   • Test with different high-quality USB cables and switch between available ports to rule out cable or port issues.

6. Power Supply Check:

   • Ensure that your power supply is adequate for both the Jetson board and any connected peripherals.

7. Consult Documentation and Community Resources:

   • Refer to NVIDIA’s official documentation for guidance on configuring USB devices and troubleshooting common issues.

8. Consider Firmware Updates:

   • Ensure that your Jetson Orin Nano is running the latest firmware and software updates, as these can resolve compatibility issues.

Recommended Fixes

• Users have found success by ensuring they are using compatible images and verifying physical connections.
• If issues persist after following these steps, consider reaching out to NVIDIA support for further assistance.

Best Practices for Future Prevention

• Always verify compatibility of hardware components before attempting a flash or setup.
• Keep updated documentation on hand regarding specific configurations and requirements for different Jetson modules.

Unresolved Aspects and Further Investigation

• Users continue to seek clarity on whether specific configurations can be reliably used across different generations of Jetson hardware.
• There may be additional troubleshooting steps required that are not fully documented in existing resources.

By following these troubleshooting steps and solutions, users can effectively address issues related to booting and USB device detection on their Jetson Orin Nano platform while ensuring compatibility with their hardware configurations.
