Jetson Orin Nano Dev Board Ethernet MAC Address Configuration Issue

Issue Overview

Users have reported difficulties in setting the Ethernet MAC address on the Nvidia Jetson Orin Nano 8GB development kit using the tegra-eeprom-tool. The primary symptoms include:

• Error in Documentation: Users have pointed out a broken sentence in the official documentation regarding customer-overwriteable MAC addresses, which adds confusion. The specific excerpt mentions: “If the value is NVCB and the version number in the system-level part number, the software builds device tree nodes for the customer-overwriteable MAC addresses.”

• MAC Address Not Changing: After attempting to set bytes 172-177 to a meaningful value and configuring byte 178 (Number of Ethernet MAC addresses) to “1”, users report that rebooting the device does not result in a change of the MAC address.

This issue primarily occurs during the configuration of network settings and is compounded by unclear documentation. The hardware involved is the Nvidia Jetson Orin Nano 8GB devkit, which utilizes a Realtek PHY for its Ethernet connection. The problem appears to be consistent, impacting users’ ability to customize network settings effectively.

Possible Causes

Several potential causes have been identified for this issue:

• Documentation Errors: The unclear sentence in the documentation may lead to misunderstandings about how to configure the MAC address.

• Driver Dependency: The Ethernet MAC address is determined by the vendor driver. For instance, if the PHY/NIC is from Realtek, it relies on Realtek’s driver, which reads the MAC address from efuse memory on the PHY rather than from EEPROM.

• Incorrect EEPROM Configuration: Users may be misconfiguring EEPROM settings without realizing that these settings do not affect MAC address changes due to driver limitations.

• Hardware Limitations: The specific hardware architecture may impose restrictions on how MAC addresses can be set or modified.

• Environmental Factors: Issues such as power supply inconsistencies could potentially impact device behavior, although this is less likely in this context.

Troubleshooting Steps, Solutions & Fixes

To address this issue effectively, users can follow these troubleshooting steps and solutions:

1. Review Documentation:

   • Carefully read through the relevant sections of the Nvidia documentation for any updates or clarifications regarding MAC address configuration.

2. Verify Driver Information:

   • Confirm that you are using the correct drivers for your hardware. For Jetson Orin Nano 8GB, ensure that you are using Realtek drivers.
   • Check if there are any updates available for these drivers that might improve functionality.

3. Check EEPROM Configuration:

   • Use tegra-eeprom-tool to verify your current EEPROM settings:

     tegra-eeprom-tool read


   • Ensure bytes 172-177 are set correctly and that byte 178 is configured to “1”.

4. Understand Driver Behavior:

   • Recognize that modifying EEPROM settings may not affect MAC address changes if your device relies on efuse memory.
   • If using Realtek PHY, understand that it reads from efuse memory instead of EEPROM. Therefore, focus on checking efuse settings if available.

5. Testing with Different Configurations:

   • If possible, test with different hardware configurations or alternative development kits to determine if the issue persists across devices.

6. Consult Community Resources:

   • Engage with community forums or Nvidia support for further insights or similar experiences shared by other users.

7. Best Practices for Future Configuration:

   • Always back up existing configurations before making changes.
   • Document any changes made for future reference.
   • Keep abreast of updates from Nvidia regarding both hardware and software changes that may affect functionality.

By following these steps, users can better diagnose and potentially resolve issues related to configuring Ethernet MAC addresses on their Jetson Orin Nano devkits.
