How to Use RTC DS3231 with Jetson Orin Nano Dev Board

Issue Overview

Users have reported difficulties integrating the DS3231 Real-Time Clock (RTC) module with the Nvidia Jetson Orin Nano Developer Kit. The main symptoms include:

• Inability to successfully install the DS3231 module and run scripts for RTC integration.
• Confusion regarding the correct wiring and connections for the DS3231 to the Jetson Orin Nano.
• Uncertainty about handling I2C communication to read time from the RTC.
• Some users have encountered errors during the installation process, particularly when building the RTC module.

The context of these issues primarily occurs during setup and configuration of the RTC module. Users have specified using Jetpack version 5.1.1, and there is mention of specific wiring connections between the Jetson Orin Nano and the DS3231 module:

• GND pin 6 → DS3231 (GND)
• VCC pin 1 → DS3231 (VCC – 3.3V)
• SCL pin 5 → DS3231 (SCL)
• SDA pin 3 → DS3231 (SDA)

The issue appears to be consistent among users who are new to the Jetson platform, affecting their ability to utilize the RTC functionality effectively.

Possible Causes

Several potential causes for these issues have been identified:

• Hardware Incompatibilities or Defects: The specific connector required for RTC integration may not be available, leading to improper connections.

• Software Bugs or Conflicts: The version of Jetpack being used may contain bugs that affect compatibility with third-party hardware like the DS3231.

• Configuration Errors: Incorrectly configured I2C settings or failure to properly install necessary drivers can lead to communication issues.

• Driver Issues: Missing or outdated drivers for I2C communication could prevent proper interaction with the RTC device.

• User Errors or Misconfigurations: New users may struggle with wiring and configuring settings correctly, especially regarding I2C addresses.

Troubleshooting Steps, Solutions & Fixes

To address the issues related to integrating the DS3231 with the Jetson Orin Nano, follow these troubleshooting steps:

1. Verify Connections:

   • Ensure that all connections between the Jetson Orin Nano and DS3231 are correct as specified:
     • GND pin 6 → DS3231 (GND)
     • VCC pin 1 → DS3231 (VCC – 3.3V)
     • SCL pin 5 → DS3231 (SCL)
     • SDA pin 3 → DS3231 (SDA)

2. Check I2C Configuration:

   • Use terminal commands to check if I2C is enabled on your system:

     sudo i2cdetect -y 1


   • This command scans for devices on I2C bus 1 and should show addresses for connected devices.

3. Install Required Libraries:

   • Ensure that you have installed necessary libraries for I2C communication. You may need to install Python libraries such as smbus or i2c-tools if they are not already present:

     sudo apt-get install python3-smbus i2c-tools


4. Install the DS3231 Module:

   • Follow specific instructions for installing the DS3231 module. If installation hangs, check logs for errors and ensure all dependencies are met.

5. Run Integration Scripts:

   • After successful installation, run scripts designed for reading from the RTC. Ensure that these scripts are compatible with Jetpack version 5.1.1.

6. Check Power Supply:

   • Verify that your power supply is adequate for both the Jetson Orin Nano and the connected RTC module.

7. Consult Documentation:

   • Refer to Nvidia’s official documentation and community forums for any updates or patches related to RTC support on Jetson devices.

8. Testing with Alternative Hardware:

   • If problems persist, consider testing with a different RTC module or a different Jetson board to isolate whether the issue is hardware-related.

9. Best Practices:

   • Always double-check wiring before powering on devices.
   • Keep your software updated to avoid compatibility issues.

10. Seek Further Assistance:

    • If unresolved, consider reaching out to Nvidia support or community forums with detailed descriptions of your setup and issues encountered.

By following these steps, users should be able to diagnose and potentially resolve their issues with integrating the DS3231 RTC module into their Jetson Orin Nano Developer Kit setup.
