How to Check Jetson Orin Nano – Camera Device Tree Issues

Issue Overview

Users of the Nvidia Jetson Orin Nano have reported confusion regarding the camera device tree configuration, particularly concerning the imx219 camera module. The main symptoms include:

• Unexpected Functionality: Users have noted that even after commenting out the inclusion of the imx219 device tree file in the main device tree source file (tegra234-p3768-0000-a0.dtsi), the imx219 camera still operates correctly when compiled and flashed to the device.

• Compilation Queries: There are questions about how to verify that the compiled device tree file matches user expectations, particularly after successful compilation.

The issue primarily arises during setup and configuration of camera modules, specifically when users attempt to modify device tree settings. The hardware involved includes the Jetson Orin Nano and specific camera modules (imx219 and others). The frequency of these issues appears to be moderate, as several users have encountered similar situations.

The problem impacts user experience by creating uncertainty in hardware configuration and functionality, leading to potential misconfigurations or reliance on undocumented behaviors.

Possible Causes

Several potential causes may explain the observed behavior:

• Hardware Compatibility: The imx219 camera might be compatible with the Jetson Orin Nano regardless of device tree settings due to fallback mechanisms in the driver or hardware support.

• Driver Behavior: The imx219 driver may not strictly require its device tree entry to function, leading to unexpected operation even when commented out.

• Configuration Errors: Users may inadvertently overlook other configurations that allow the camera to function outside of expected parameters.

• Environmental Factors: Power supply or thermal conditions could also affect hardware performance but are less likely to cause this specific issue.

Understanding these causes can help users identify why their configurations behave unexpectedly.

Troubleshooting Steps, Solutions & Fixes

To address the issues related to the camera device tree on the Jetson Orin Nano, follow these troubleshooting steps:

1. Verify Driver Installation:

   • Ensure that the driver for imx219 is installed correctly.
   • Use the command:

     lsmod | grep imx219


   • This command checks if the driver is loaded.

2. Check Device Tree Compilation:

   • After modifying tegra234-p3768-0000-a0.dtsi, compile your device tree using:

     make dtbs


   • This will generate a new device tree blob (dtb) file.

3. Locate Compiled Device Tree Files:

   • Navigate to the output directory:

     cd Linux_for_Tegra/source/public/kernel_out/arch/arm64/boot/dtb/nvidia/


   • Verify that your changes are reflected in the newly generated dtb files.

4. Inspect Device Tree Blob:

   • Use a tool like dtc (Device Tree Compiler) to decompile and inspect your dtb file:

     dtc -I dtb -O dts -o output.dts your_device_tree_file.dtb


   • Review output.dts for expected entries related to imx219.

5. Testing Camera Functionality:

   • Test if the imx219 camera operates as expected using GStreamer or another application:

     gst-launch-1.0 v4l2src ! videoconvert ! autovideosink


6. Consult Documentation:

   • Refer to Nvidia’s official documentation for additional insights on device trees and camera configurations.
   • Keep an eye on firmware updates that may address underlying issues.

7. Best Practices:

   • Always back up original device tree files before making modifications.
   • Document changes made for future reference.
   • Regularly check for updates in forums or Nvidia’s developer resources for new solutions or patches.

By following these steps, users can effectively troubleshoot and resolve issues related to camera device trees on the Jetson Orin Nano. If problems persist, further investigation into specific configurations or environmental factors may be necessary.
