Error when trying to capture from IMX219 (Pi Camera v2) on fresh JetPack 5.1.2 install

Issue Overview

Users are experiencing issues when attempting to capture video from the IMX219 (Raspberry Pi Camera v2) on the Nvidia Jetson Orin Nano development board after a fresh installation of JetPack 5.1.2. The primary symptoms include error messages related to encoder configuration and initialization failures when running the nvgstcapture-1.0 command.

The specific errors reported include:

• Encoder null, cannot set bitrate!
• Codec not supported. Falling back to opensrc H264 encoder
• Multiple instances of (Argus) Error BadParameter indicating failures in creating FrameConsumer and initializing EGLDisplay.

These errors occur during attempts to capture video, indicating potential issues with camera recognition or configuration. The problem arises consistently, suggesting a systemic issue rather than isolated incidents.

The hardware setup involves using a 15-pin to 22-pin connector connected to CAM0 on the Orin Nano dev kit. The user has also reported relevant outputs from the dmesg command, which indicate problems with I2C communication during sensor initialization.

Possible Causes

• Hardware Incompatibilities or Defects: The use of an incorrect or faulty connector could lead to communication failures between the camera and the Orin Nano, resulting in initialization errors.

• Software Bugs or Conflicts: There may be bugs in the JetPack version being used that affect camera functionality, particularly with specific configurations or drivers.

• Configuration Errors: Incorrect settings in the camera pipeline or environment variables could prevent successful initialization and operation of the camera.

• Driver Issues: The camera driver may not be compatible with the current version of JetPack installed, leading to failures in recognizing or configuring the camera.

• Environmental Factors: Issues such as incorrect power supply or overheating could impact device performance and lead to failure during operation.

• User Errors or Misconfigurations: Users may not have properly configured their environment settings, such as display variables necessary for EGL display connections.

Troubleshooting Steps, Solutions & Fixes

1. Check Hardware Connections:

   • Ensure that the FFC cable is securely connected and properly seated. Reseating the cable has resolved issues for some users.

2. Verify Environment Variables:

   • Set the DISPLAY variable by executing:

     export DISPLAY=:0


   • Run xrandr to check display configuration and ensure it is correctly set up.

3. Test Basic Camera Functionality:

   • Use the following command to test if the camera can be accessed:

     gst-launch-1.0 nvarguscamerasrc ! fakesink


   • Monitor for any error messages that indicate issues with initialization.

4. Check Kernel Messages:

   • Review kernel messages for any additional clues by running:

     sudo dmesg | grep imx


   • Look for errors related to I2C communication or sensor initialization.

5. Update Software and Drivers:

   • Ensure that you are using the latest version of JetPack and all associated drivers. Check Nvidia’s official documentation for updates or patches that may resolve known issues.

6. Adjust Camera Settings:

   • If applicable, try changing settings related to bitrate or codec profiles within your capture commands to see if different configurations yield better results.

7. Consult Documentation:

   • Refer to Nvidia’s official documentation for Jetson devices regarding camera setup and troubleshooting, ensuring all steps have been followed correctly.

8. Testing with Different Configurations:

   • If possible, test with another camera module or different connectors to rule out hardware-specific issues.

9. Report Unresolved Issues:

   • If all troubleshooting steps fail, consider reporting unresolved issues on forums or directly to Nvidia support for further assistance.

By following these steps, users should be able to diagnose and potentially resolve issues related to capturing video from the IMX219 camera on their Jetson Orin Nano development board.
