Deploying Edge AI Web Apps on Jetson Orin Nano: A Comprehensive Guide

Issue Overview

The Nvidia Jetson Orin Nano Developer Kit is a powerful, energy-efficient AI server designed for edge computing applications. This guide addresses the deployment of AI-powered web applications on the Jetson Orin Nano, focusing on recent updates to the "Hello AI World" project. The main aspects covered include:

• Implementing live web interfaces for AI applications
• Utilizing WebRTC for low-latency video streaming
• Building interactive learning and development tools
• Enabling user-driven data tagging and model tuning
• Overcoming challenges in edge ML and embedded systems

The Jetson Orin Nano, with its 40 teraops of computing power, can perform DNN inferencing across multiple streams, retrain models, and host web services locally.

Possible Causes

While the forum discussion doesn’t explicitly mention issues, potential challenges in deploying Edge AI Web Apps on Jetson Orin Nano could include:

1. Hardware limitations: Despite its power, the Jetson Orin Nano may struggle with extremely resource-intensive applications.
2. Software compatibility: Ensuring all required libraries and frameworks are compatible with the Jetson platform.
3. Network constraints: Bandwidth limitations affecting video streaming quality.
4. Configuration complexities: Proper setup of WebRTC and other communication protocols.
5. Performance optimization: Balancing between AI processing and web hosting on a single device.

Troubleshooting Steps, Solutions & Fixes

1. Implementing WebRTC for Video Streaming

To enable low-latency video streaming:

1. Update to the latest version of Hello AI World.
2. Use the webrtc:// protocol in your video streaming APIs:

$ detectnet.py --model=peoplenet /dev/video0 webrtc://@:8554/output

3. Access the stream by navigating to your Jetson’s IP on port 8554 in a web browser.

2. Building AI-Powered Web Applications

Several examples are provided for creating frontends:

• Javascript/HTML5/CSS: For basic web interfaces
• Flask + REST: Used in the DNN Playground example
• Plotly Dash: For creating interactive dashboards
• Recognizer: An example of interactive training

3. Utilizing Jetson Orin Nano’s Capabilities

To leverage the full potential of the Jetson Orin Nano:

1. Explore multi-stream processing for various sensor modalities.
2. Implement local model retraining and fine-tuning.
3. Host web services directly on the device for edge processing.

4. Integrating Additional Features

Recent updates to Hello AI World include:

• Support for TAO detection models in detectNet (INT8)
• Action/behavior recognition (actionNet)
• Foreground/background segmentation & removal
• Multi-label image tagging
• Basic object tracking for detectNet

5. Enhancing Python Interoperability

For improved Python integration:

1. Utilize the Python cudaImage zero-copy interoperability with:
   • PyTorch
   • Numba
   • CuPy
   • PyCUDA
   • VPI
   • Other compatible libraries

6. Expanding Output Options

To increase flexibility in data output:

1. Implement RTSP output (RTSP input was already supported).

7. Cross-Platform Development

For development across different platforms:

1. Utilize x86+dGPU Docker support
2. Consider using WSL2 for Windows-based development

8. Seeking Additional Support

If you encounter issues or need further assistance:

1. Post an issue on the Hello AI World GitHub repository
2. Seek help on the Jetson forums

By following these steps and utilizing the provided resources, developers can effectively deploy Edge AI Web Apps on the Jetson Orin Nano, taking advantage of its powerful capabilities for edge computing and AI processing.
