CSI Camera Initialization Error in Docker Container on Jetson Orin Nano
Issue Overview
Users of the Nvidia Jetson Orin Nano 8GB developer kit are experiencing difficulties initializing the CSI camera (IMX219) within a Docker container. The issue specifically occurs when attempting to create a CSICamera object using the jetcam library. While the camera functions correctly outside the container, users encounter a RuntimeError when trying to initialize it inside the Docker environment. This problem is preventing users from proceeding with the "Getting Started with AI on Jetson Nano" course materials within the containerized setup.
Possible Causes
-
Incompatible Docker Image: The Docker image being used (nvcr.io/nvidia/dli/dli-nano-ai:v2.0.2-r32.7.1) is designed for JetPack 4 and the original Jetson Nano, not for the Orin Nano running JetPack 5.
-
Missing GStreamer Element: The error message indicates that the "nvarguscamerasrc" GStreamer element is not found, which is crucial for camera initialization.
-
Incorrect Device Mapping: The Docker run command may not be correctly mapping the camera device into the container.
-
Jetcam Installation Issues: There might be problems with the jetcam library installation or compatibility within the Docker container.
-
JetPack Version Mismatch: The software stack inside the container may not be compatible with the JetPack version running on the Orin Nano.
Troubleshooting Steps, Solutions & Fixes
-
Use a Compatible Docker Image
- Instead of using the nvcr.io/nvidia/dli/dli-nano-ai:v2.0.2-r32.7.1 image, switch to nvcr.io/nvidia/l4t-ml:r35.2.1-py3.
- Run the container with the following command:
sudo docker run --runtime nvidia -it --rm --network host \ --volume ~/nvdli-data:/nvdli-nano/data \ --volume /tmp/argus_socket:/tmp/argus_socket \ --device /dev/video0 \ nvcr.io/nvidia/l4t-ml:r35.2.1-py3
-
Install Jetcam in the New Container
- Once inside the container, install jetcam:
pip install jetcam
-
Mount Notebooks and Necessary Files
- Ensure that you mount any required notebooks or files into the container using the
--volume
flag in the docker run command.
- Ensure that you mount any required notebooks or files into the container using the
-
Verify GStreamer Elements
- Check if the required GStreamer elements are present in the container:
gst-inspect-1.0 nvarguscamerasrc
If missing, you may need to install additional packages or ensure proper NVIDIA drivers are installed.
-
Check Camera Device
- Verify that the camera device is correctly passed to the container:
ls -l /dev/video*
Ensure that /dev/video0 (or the appropriate device) is present.
-
Adjust CSICamera Initialization
- Try different capture device numbers or camera settings:
camera = CSICamera(width=224, height=224, capture_device=0) # Try capture_device=1 or other numbers if 0 doesn't work
-
Use Hello AI World Tutorial
- If the issues persist, consider switching to the "Hello AI World" tutorial, which is fully supported on Orin and JetPack 5:
- Visit the GitHub repository: dusty-nv/jetson-inference
- Follow the installation and setup instructions provided in the repository.
-
Check JetPack Compatibility
- Ensure that you are using the correct JetPack version for your Orin Nano.
- Verify that all software components are up to date:
sudo apt update && sudo apt upgrade
-
Investigate Argus Socket
- Check if the Argus socket is properly mapped and accessible within the container:
ls -l /tmp/argus_socket
Ensure that the permissions allow the container to access this socket.
-
Enable Debug Logging
- To get more detailed error information, enable debug logging for the camera initialization:
import logging logging.basicConfig(level=logging.DEBUG)
Run this before initializing the camera to get more verbose output.
If these steps do not resolve the issue, consider reaching out to NVIDIA developer forums or support channels for more specific assistance related to the Jetson Orin Nano and its compatibility with the AI course materials.
