Can I use SSD for M.2 2230 with M.2 2280 slot on Jetson Orin Devkit Carrier Board?

Issue Overview

Users are experiencing confusion regarding the compatibility of M.2 2230 NVMe SSDs with the M.2 2280 slots on the Jetson Orin Devkit carrier board. The main symptoms include uncertainty about whether these SSDs can be used in the specified slots, and users are seeking recommendations for compatible SSDs. This issue arises during the setup phase of using the Jetson Orin Nano Developer Kit, specifically when attempting to integrate storage solutions. The Jetson Orin Nano Developer Kit is designed for AI-powered applications, and ensuring proper hardware compatibility is crucial for optimal performance. The issue appears to be consistent among users, impacting their ability to proceed with development tasks effectively.

Possible Causes

• Hardware Incompatibilities: The M.2 slot specifications may not support M.2 2230 SSDs, leading to connection issues.
• Configuration Errors: Users might not be aware of the specific requirements for SSD installation, such as key types or slot dimensions.
• Driver Issues: Lack of appropriate drivers for new hardware could prevent recognition of the SSD.
• User Errors: Misunderstanding of the specifications or installation procedures could lead to improper setup.

Troubleshooting Steps, Solutions & Fixes

1. Check Compatibility:

   • Refer to the Jetson Orin Nano Developer Kit specifications in DLC 4 to confirm the key type and dimensions of the M.2 slots available.
   • Review the SCL 4 document for recommended components.

2. Installation Instructions:

   • Ensure that the SSD is properly seated in the slot.
   • If using an M.2 2230 SSD, verify that it fits securely within an M.2 2280 slot.

3. Driver Verification:

   • Update drivers by downloading the latest from NVIDIA’s official website or using the SDK Manager.
   • Use terminal commands to check if the system recognizes the SSD:

     lsblk


     This command lists all block devices and can help identify if the SSD is detected.

4. Testing Different Configurations:

   • If issues persist, test with another known compatible SSD to isolate whether the problem lies with the original SSD or the board itself.

5. Firmware Updates:

   • Check if there are any firmware updates available for your Jetson Orin Nano Developer Kit that may improve compatibility with various storage devices.

6. Best Practices:

   • Always ensure that power supply requirements are met (19V for Orin Nano).
   • Follow proper shutdown procedures to avoid data corruption on SSDs.

7. Documentation and Resources:

   • Consult NVIDIA’s official documentation, including:
     • Getting Started with NVIDIA Jetson Orin Nano Developer Kit [1]
     • Jetson Linux Developer Guide [5]

8. Community Support:

   • Engage with community forums such as NVIDIA’s developer forums for additional troubleshooting tips and shared experiences from other users facing similar issues.

By following these steps, users should be able to determine compatibility and successfully integrate their chosen SSD into their Jetson Orin Nano setup.
